Ultrasonic Thickness Gauge Lee320/321/322
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Name: | Ultrasonic Thickness Gauge Lee320/321/322 |
|---|
Ultrasonic Thickness Gauge Lee320/321/322
Functions & Features
●Integrated with a 4mm calibration block
●Two display units: mm and inch.
●With coupling state indication.
●Measuring sound velocity: according to the known thickness of the object, sound velocity of it can be measured directly.
Measuring Materials
Adapted to all kinds of materials which are good conductor of ultrasonic wave, such as metals(steel, cast iron, aluminum, copper and etc), plastic, ceramics, composites, epoxies, glass and etc.
Technical Parameters
| Model | Leeb320 | Leeb321 | Leeb322 |
| Measuring range(mm) | 0.7~300 | ||
| Resolution(mm) | 0.1 | 0.01 | |
| Accuracy(mm) | ±(1%H+0.1) | ±(0.5%H+0.01) | |
| Storage | No | 500 Groups | |
| Shell | Plastic | ||
| Operating Temperature | (-10°C~60°C) | ||
| Dampness | 20%~90% | ||
| Dimensions(mm) | 130×70×250 | ||
| Power supply | AAA alkaline batteries | ||
| Weight (g) | 200g | ||
| Velocity range(m/s) | 5920 | 1000~9999 | |
