Beidou GPS Data Collector (Pathfinder S501)

China Beidou GPS Data Collector (Pathfinder S501) supplier
Beidou GPS Data Collector (Pathfinder S501) supplier Beidou GPS Data Collector (Pathfinder S501) supplier Beidou GPS Data Collector (Pathfinder S501) supplier

Large Image :  Beidou GPS Data Collector (Pathfinder S501)

Product Details:

Place of Origin: China
Brand Name: Huaneng Wei Tong
Certification: CE
Model Number: Beidou GPS Data Collector (Pathfinder S501)

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Packaging Details: with standard packing way
Delivery Time: 3-5 work days after the goods are paid
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 5000000 per pc
Contact Now
Detailed Product Description





Beidou GPS Data Controller  Pathfinder S501


Strong Kernel configuration of Intelligent operating system:



Mainstream Android 5.1 operating system, main frequency 1.6 GHz, high-performance 8-core CPU 1GB RAM running 16GB ROM memory, the maximum extensible 64G. Professional high precision Beidou RTD mapping module, anti-shielding extremely strong, all-weather, more sensitive and accurate all-around search for stars.



Professional data acquisition software:



Professional Android handheld GPS software, easy to operate, with navigation points, routes, track acquisition, editing, navigation and other functions, a variety of area measurement, simple, efficient and accurate area calculation, coordinate data and photo combination, and achieve photo navigation, It can support Google remote sensing image map and Baidu electronic map. It can also use online map off-line package, support users to load map such as: shpmmif format, and many GIS data output formats. Meet all data processing requirements.



Industrial triple-proof durable:



Industrial grade three defense standards, P67 protection grade, waterproof, dustproof, shockproof, high resistance and high durability, easy to cope with bad extreme environment, rigid body design, and equipped with knapsack, easy to carry.

Beidou GPS Data Collector (Pathfinder S501)



Technical specifications

Operating system   Android 5.1
(OS)


Processor     Eight-core pole processor, main frequency: 1.6GHz

Receiver     RTD surveying and Mapping Module of Beidou Specialty with High sensitivity

Positioning accuracy   Single point position: 1-3 m
    SBAS: 1-2 m


Height     Error of high precision waterproofing height of professional grade 1.2m accuracy

Display screen   Screen size: 4.5 "WVGA, reflective display, visible in strong light

Numeric keyboard   Industrial T9 professional keyboard, 21 master keys, more convenient operation

Data interface   MiniUSB 2.0,Support MiniUSB serial data communication

Beidou satellite   High precision Beidou second generation satellite system GPS system, data update, 1 second time
system


      Supporting OTGG FM / WCDMA 850 / 1900 / 2100 three Frequency support for All-Netcom
      4G
Communications   GSM850 / 900 / 1800 / 1900, Bluetooth WiFi, motion sensors,
and others

      Gravity sensors, electronic compasses, gyroscopes, NFC near-field communications,


thermometers, barometers (optional)





RFID/ PMAS   Optional function: UHF RFID UHF passive tag Reader (1.5M-2M) / PSAM data encryption (1.8 / 3.3V
  standard PSAM card reader interface)

Storage   R A: 1GB running, ROM: 16GB storage
  Extension: maximum support for MircoSD card extension 64G storage


Electric source   Battery capacity: 4500mAh (detachable), life span: 14 hours or more

Size   198mm x 92mm x 26.5mm (long x wide x thick), weight: about 380g (including batteries)

Three prevention IP67, resistance 1.8 metres to ground

Photo head   HD 13 million pixel camera

Multifunctional
charging base Select and match: 15000 mAh power output USB port, double LED lighting, laser indicator
charge

Standby note   Standard accessories: waist x1, host x1, battery x1, warranty card x1, certificate x1, anti-counterfeiting
  label x 1, professional waterproof USB data line * 1
