Product Details:
Payment & Shipping Terms:
|
Data Format
RTCM2.1, RTCM2.3 , RTCM3.0, CMR, RTCA, Input and Output
NMEA 0183 outputs, GSOF outputs
Technical Parameters:
RTK | ||
Horizontal: | +(10mm+1ppm)RMS | |
Vertical: | +(20mm+1ppm)RMS | |
Initializing Time: | 10S | |
Initialization Reliability: | Typical>99.9% | |
Static | ||
Horizontal: | +(2.5mm+1ppm)RMS | |
Vertical: | +(5mm+1ppm)RMS | |
Physical Reference | ||
Size (HXD): | 80mmX180mm | |
Weight: | 1.25kg (Battery Included) | |
Electronic Reference | ||
Power Consumption: | 2.6W | |
Battery Volume: | 2400mAh | |
Battery Life: |
9 Hours (Static) 5 Hours (RTK) 1000 Recharges |
|
External Power: | 9-18 VDC | |
Environment | ||
Working Temperature: | -30- +65 | |
Storage Temperature: | -40-+75 | |
Humidity: | 100% condensation | |
Waterproof and Dustproof: |
IP67, protected from temporary immersion to depth of 1 meter, floating. |
|
Shock and Vibration: |
Survive from 2 meters drop onto concretes |
|
Characteristics | ||
Buttons and Display: | 2 buttons/4 LED lights | |
I/O: |
RS232, High-speed USB, Bluetooth |
|
Channel: | 220 Channels | |
Datalink | ||
Power (UHF): | 1W-20W Adjustable | |
Band Width: |
410-430 MHz / 430-450 MHz / 450-470 MHz |
