South RTK GPS Galaxy G1

China South RTK GPS Galaxy  G1 supplier
South RTK GPS Galaxy  G1 supplier South RTK GPS Galaxy  G1 supplier South RTK GPS Galaxy  G1 supplier

Large Image :  South RTK GPS Galaxy G1

Product Details:

Place of Origin: China
Brand Name: South
Certification: CE
Model Number: South RTK GPS Galaxy G1

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Packaging Details: with standard packing way
Delivery Time: 3-5 work days after the goods are paid
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 5000000 per pc
Contact Now
Detailed Product Description

South RTK GPS Galaxy G1


South RTK GPS Galaxy  G1


South RTK GPS Galaxy  G1



●Innovative structure design
●Powerful new bluetooth module
●Tilt survey
●Electronic bubble correct
●Full satellite constellations support
●Intelligent and open platform
●Cloud service
●Advanced data-link module
●NFC function



SOUTH Galaxy G1, new generation integrated RTK system with smaller size and innovative design, leads the direction of new generation RTK with excellent performance, provides high-efficiency and intelligent surveying experience to customers. It isn't simply smaller, it's better in everywhere.


Technical Specifications

Best Quality Measuring GNSS Receiver South Galaxy G1 gps gnss rtk receiver in dual frequency with best price and service

SOUTH Galaxy G1
Surveying Performance
Channel 220 Channels
Signal Tracking BDS B1, B2, B3,
GPS L1C/A, L1C, L2C, L2E, L5
SBAS L1C/A, L5( Just for the satellites supporting L5 )
Galileo GIOVE-A, GIOVE-B, E1, E5A, E5B
GNSS Feature Positioning output rate: 1HZ~50HZ
Initialization time : <10s
Initialization reliability : >99.99%
Positioning Precision
Code Differential GNSS Positioning Horizontal: 0.25 m + 1 ppm
Vertical: 0.50 m + 1 ppm
SBAS positioning accuracy: typically<5m 3DRMS
Static GNSS Surveying Horizontal: 2.5 mm + 0.5 ppm
Vertical: 5 mm + 0.5 ppm
Real-Time Kinematic Surveying (Baseline<30km) Horizontal: 8 mm + 1 ppm
Vertical: 15 mm + 1 ppm
Horizontal: 8 mm + 0.5 ppm
Vertical: 15 mm + 0.5 ppm
Network RTK RTK initialization time: 2~8s
Dimension 12.9cm × 11.2cm
Weigh 970g(includiing installed battery)
Material Magnesium aluminum alloy shell
Operating -45ºC~+60ºC
Storage -55ºC~+85ºC
Humidity Non-condensing
Waterproof/Dustproof IP67 standard,protected from long time immersion to depth of 1m
IP67 standard,fully protected against blowing dust
Shock and Vibration Not operating: Withstand 2 meters pole drop onto the cement ground naturally
operating : Withstand 40G 10milliseconds sawtooth wave impact test
Power consumption 2W
Battery Rechargeable, removable Litium-ion battery
Battery Life Single battery: 7h( static mode ) 5h( interual UHF base mode )
6h( rover mode )
Communications and Data storage
I/O Port 5PIN LEOM external power port + RS232
1 network/radio data link antenna port
SIM card slot
Wireless Modem Integrated internal radio receiver and transmitter 0.5W/2W
External radio transmitter 5W/25W
Working frequency 410-470MHz
Communication protocol TrimTalk450s, TrimMark3, PCC EOT, SOUTH
Cellular Mobile Network WCDMA3.5G network communication module, GPRS/EDGE compatible, CDMA2000/EVDO
3G optional
Double Module Bluetooth BLEBluetooth 4.0 standard, support for android, ios cellphoon connection
Bluetooth + EDR standard
NFC communication Realizing close range ( shorter than 10cm ) automatic pair between Galxy G1 and controller
(controller equipped NFC wireless communication module needed)
Data storage/Transmission 4GB internal storage, more than 3 year raw observation data (1.4M/day) base on recording from 14 satelites Plug and play more of USB data transmission
Data Format Differential data format: CMR+, CMRx, RTCM2.1, RTCM2.3, RTCM3.0, RTCM3.1, RTCM3.2
  GPS output data format: NMEA0813, PJK plan, cordinates binary code
  Network model support: various, FKP, MAC, supporting NTRIP protocol
Intertial Sensing System
Tilt survey Built-in tilt compensator, correcting coordinates automaticlly according to the tilt direction and angle of the centering rod
Electornic Bubble Conteroller software display electronic bubble, checking leveling status of the centering rod real time
User Interaction
Buttons One-button operation, Visual operation, convenient and efficient
