Nikon Total Station DTM352

Large Image : Nikon Total Station DTM352

Product Details:

Place of Origin:	China
Brand Name:	Nikon
Certification:	CE
Model Number:	DTM352

Payment & Shipping Terms:

Minimum Order Quantity:	1
Packaging Details:	With Standard Packing Way
Payment Terms:	T/T, L/C, Western Union
Supply Ability:	1000 per year

Contact Now

Detailed Product Description

±(3+2ppm x D)mm distance measurement accuracy

Same distance accuracy for both Prisms and Reflector Sheet

Just 1.6 sec. measuring time with 1mm distance resolution

5-second angle measurement accuracy

Quick and convenient feature code input system

USR user defined keys set as “ONE-TOUCH access” keys to your preferred functions

User customizable feature code list

First, on-site setting change capability

Feet & Inch input and display

A special version of the DTM-352 that allows operation at extremely low temperatures down to –30°C is available.

Nikon Total Station DTM352

SPECIFICATION :

Model	DTM-362, DTM-352, DTM-332
Telescope
Tube Length	158mm/6.22 in.
Magnification	33x (21x/41x with optional eyepieces)
Effective diameter of objective	45mm/1.77 in. (EDM: 50mm/1.97 in.)
Field of view	1°20’
Resolving power	2.5”
Minimum focusing distance	1.3m/4.26 ft.
Distance measurement
Range with Nikon specified prisms
Normal conditions	(Ordinary haze, visibility approx. 20km/12.5 miles)
With reflector sheet (5 x 5cm)	5 to 100m (16.4 to 328 ft.)
With mini prism	1,000m/3,280 ft.
With single prism	2,000m/6,560 ft
With triple prism	2,600m/8,530 ft.
Good conditions	(No haze, visibility of over 40km/25 miles)
With reflector sheet (5 x 5cm)	5 to 100m (16.4 to 328 ft.)
With mini prism	1,200m/3,930 ft.
With single prism	2,300m/7.540 ft.
With triple prism	3,000m/9,840 ft.
Accuracy (Prism/Precise mode)	±(3+2ppm x D)mm ±(3+3ppm x D)mm (–20°C to –10°C, +40°C to +50°C
Measuring interval^*1
Precise mode	1.6 sec. (initial 1.6 sec.)
Normal mode	1.0 sec. (initial 1.4 sec.)
Least count
Precise mode	1mm/0.002 ft.
Normal mode	10mm/0.02 ft.
Ambient temperature range^*2	–20°C to 50°C/–4°F to +122°F
Atmospheric correction
Temperature range	–40°C to 60°C/–40°F to +140°F
Barometric pressure	400 to 999mmHg/533 to 1,332hPa/15.8 to 39.3 in.Hg
Prism offset	–999 to 999
Angle measurement
Reading system	Photoelectric detection by incremental encoder
Horizontal angle	Diametrical(DTM-362/352), Single(DTM-332)
Vertical angle	Single
Minimum increment (Degree, Gon, MIL6400)	Degree: 1/5/10”, Gon: 0.2/1/2mgon, MIL6400: 0.005/0.02/0,05mil
DIN 18723 accuracy (horizontal and vertical)	5”/1.5mgon (3”/1.0mgon:DTM-362)
Tilt sensor
Type	Dual-axis(DTM-362/352), Single-axis(DTM-332)
Method	Liquid-electric detection
Compensation range	±3'
Setting accuracy	1"
Level vial
Plate level vial	30"/2mm
Circular level vial	10'/2mm
Optical plummet
Magnification	3x
Focusing range	0.5m/1.6 ft. to ∞
Display	Graphic LCD (128 x 64 dot) Both sides(DTM-362/352), Single side(DTM-332)
Point memory	10,000 records
Dimensions (W x D x H)	168 x 173 x 335mm/6.6 x 6.8 x 13.2 in.
Weight (approx.)
Main unit (with battery)	5.3kg/11.7 lbs.(DTM-362/352), 5.2kg/11.5 lbs.(DTM-332)
Battery	0.4kg/0.9 lbs
Carrying case	2.4kg/5.3 lbs
On-board Ni-MH battery BC-65
Operation time
Continuous distance/angle measurement	Approx. 16 hours^*3
Distance/angle measurement every 30 seconds	Approx. 27 hours
Angle measurement	Approx. 30 hours
Battery charger for BC-80/65	Approx. 2.0 hours for full recharge
Quick charger Q-70C (12V DC cigarette lighter charger)	Approx. 2.0 hours (fully discharged BC-65 requires more than one charge)
